Carte Mère Z97-D3H 1150 Z97 ATX 4DDR3 PCIe SATA GbE VHD Gigabyte

Processeur
1.Support for Intel® Core™ i7 processors/Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1150 package
2.L3 cache varies with CPU
(Please refer "CPU Support List" for more information.)
Chipset 1.Intel® Z97 Express Chipset

Mémoire
1.4 x DDR3 DIMM sockets supporting up to 32 GB of system memory
 * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.
2.Dual channel memory architecture
3.Support for DDR3 3100(O.C.) / 3000(O.C.) / 2933(O.C.) / 2800(O.C.) / 2666(O.C.) / 2600(O.C.) / 2500(O.C.) / 2400(O.C.) / 2200(O.C.) / 2133(O.C.) / 2000(O.C.) / 1866(O.C.) / 1800(O.C.) / 1600 / 1333 MHz memory modules
4.Support for non-ECC memory modules
5.Support for Extreme Memory Profile (XMP) memory modules
(Please refer "Memory Support List" for more information.)
Carte Graphique Intégrée Integrated Graphics Processor: 1.1 x D-Sub port, supporting a maximum resolution of 1920x1200@60Hz
2.1 x DVI-D port, supporting a maximum resolution of 1920x1200@60Hz
 * The DVI-D port does not support D-Sub connection by adapter.
3.1 x HDMI port, supporting a maximum resolution of 4096x2160@24Hz or 2560x1600@60Hz
 * Support for HDMI 1.4a version.
4.Support for up to 3 displays at the same time
5.Maximum shared memory of 512MB

Audio
1.Realtek® ALC1150 codec
2.High Definition Audio
3.2/4/5.1/7.1-channel
4.Support for S/PDIF Out

Réseau
1.Intel® GbE LAN chip (10/100/1000 Mbit)

Port d'expansion
1.1 x PCI Express x16 slot, running at x16 (PCIEX16)
 (The PCIEX16 slot conforms to PCI Express 3.0 standard.)
 * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.

2.1 x PCI Express x16 slot, running at x4 (PCIEX4)
 * The PCIEX4 slot shares bandwidth with all PCI Express x1 slots. All PCI Express x1 slots will become unavailable when a PCIe x4 expansion card is installed.
 * When installing a x8 or above card in the PCIEX4 slot, make sure to set PCIE Slot Configuration in BIOS Setup to x4. (Refer to Chapter 2, "BIOS Setup," "Peripherals," for more information.)

3.2 x PCI Express x1 slots
 (The PCIEX4 and the PCI Express x1 slots conform to PCI Express 2.0 standard.)

4.3 x PCI slots

Technologie Multi-cartes graphiques
1.Support for AMD CrossFire™ technology

Interface de Stockage
Chipset:
1.1 x M.2 PCIe connector
 (Socket 3, M key, type 2242/2260/2280 SATA & PCIe SSD support)
2.1 x SATA Express connector
3.6 x SATA 6Gb/s connectors
 (M.2, SATA Express, and SATA3 4/5 connectors can only be used one at a time. The SATA3 4/5 connectors will become unavailable when an M.2 SSD is installed.)
4.Support for RAID 0, RAID 1, RAID 5, and RAID 10

USB Chipset:
1.6 x USB 3.0/2.0 ports (4 ports on the back panel, 2 ports available through the internal USB header)
2.8 x USB 2.0/1.1 ports (2 ports on the back panel, 6 ports available through the internal USB headers)

Connecteurs d'entrées/sorties internes
1.1 x 24-pin ATX main power connector
2.1 x 8-pin ATX 12V power connector
3.1 x M.2 PCIe connector
4.1 x SATA Express connector
5.6 x SATA 6Gb/s connectors
6.1 x USB 3.0/2.0 header
7.3 x USB 2.0/1.1 headers
8.1 x CPU fan header
9.1 x water cooling fan header (CPU_OPT)
10.3 x system fan headers
11.1 x front panel header
12.1 x front panel audio header
13.1 x serial port header
14.1 x Trusted Platform Module (TPM) header
15.1 x S/PDIF Out header
16.1 x Clear CMOS jumper

Connecteur du Panneau Arrière
1.1 x PS/2 keyboard/mouse port
2.1 x D-Sub port
3.1 x DVI-D port
4.1 x HDMI port
5.4 x USB 3.0/2.0 ports
6.2 x USB 2.0/1.1 ports
7.1 x RJ-45 port
8.6 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out, Line In, Line Out, Mic In)

Contrôleur d'Entrée/Sortie
1.iTE® I/O Controller Chip

Monitorage Matériel
1.System voltage detection
2.CPU/System temperature detection
3.CPU/CPU OPT/System fan speed detection
4.CPU/System overheating warning
5.CPU/CPU OPT/System fan fail warning
6.CPU/CPU OPT/System fan speed control
 * Whether the fan speed control function is supported will depend on the cooler you install.

BIOS
1.2 x 64 Mbit flash
2.Use of licensed AMI UEFI BIOS
3.Support for DualBIOS™
4.PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Fonctionnalités Exclusives
1.Support for APP Center
 * Available applications in APP Center may differ by motherboard model. Supported functions of each application may also differ depending on motherboard specifications.
 @BIOS
 EasyTune
 EZ Setup
 Fast Boot
 ON/OFF Charge
 Smart TimeLock
 Smart Recovery 2
 System Information Viewer
 USB Blocker
2.Support for Q-Flash
3.Support for Smart Switch
4.Support for Xpress Install

Logiciels Fournis
1.Norton® Internet Security (OEM version)
2.Intel® Rapid Start Technology
3.Intel® Smart Connect Technology
4.Intel® Smart Response Technology
5.cFosSpeed

Système d'Exploitation 1.Support for Windows 8.1/8/7

Dimensions 1.ATX Form Factor; 30.5cm x 21.4cm

Remarque 1.Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
2.Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
