Carte Mère H97M-D3H 1150 H97 mATX 4DDR3 PCIe SATA 6G Gigabyte

Processeur :
 1.Support for Intel® Core™ i7 processors/Intel® Core™ i5 processors/ Intel® Core™ i3 processors/Intel® Pentium® processors/ Intel® Celeron® processors in the LGA1150 package
2.L3 cache varies with CPU
(Please refer "CPU Support List" for more information.)

Chipset :
1.Intel® H97 Express Chipset

Mémoire :
1.4 x DDR3 DIMM sockets supporting up to 32 GB of system memory
 * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.
2.Dual channel memory architecture
3.Support for DDR3 1600/1333 MHz memory modules
4.Support for non-ECC memory modules
5.Support for Extreme Memory Profile (XMP) memory modules
(Please refer "Memory Support List" for more information.)

Carte Graphique Intégrée :
Integrated Graphics Processor - Intel® HD Graphics support: 1.1 x D-Sub port, supporting a maximum resolution of 1920x1200@60Hz
2.1 x DVI-D port, supporting a maximum resolution of 1920x1200@60Hz
 * The DVI-D port does not support D-Sub connection by adapter.
3.1 x HDMI port, supporting a maximum resolution of 4096x2160@24Hz or 2560x1600@60Hz
 * Support for HDMI 1.4a version.
4.Support for up to 3 displays at the same time
5.Maximum shared memory of 512MB

Audio :
1.Realtek® ALC892 codec
2.High Definition Audio
3.2/4/5.1/7.1-channel
4.Support for S/PDIF Out

Réseau :
1.Realtek® GbE LAN chip (10/100/1000 Mbit)

Port d'expansion :
1.1 x PCI Express x16 slot, running at x16 (PCIEX16)
 * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
 (The PCIEX16 slot conforms to PCI Express 3.0 standard.)
2.1 x PCI Express x16 slot, running at x4 (PCIEX4)
 (The PCIEX4 slot conforms to PCI Express 2.0 standard.)
3.2 x PCI slots

Technologie :
Multi-cartes graphiques 1.Support for 2-Way AMD CrossFire™ technology

Interface de Stockage :
Chipset: 1.6 x SATA 6Gb/s connectors
2.Support for RAID 0, RAID 1, RAID 5, and RAID 10

USB :
Chipset: 1.6 x USB 3.0/2.0 ports (4 ports on the back panel, 2 ports available through the internal USB header)
2.8 x USB 2.0/1.1 ports (2 ports on the back panel, 6 ports available through the internal USB headers)

Connecteurs d'entrées/sorties internes :
1.1 x 24-pin ATX main power connector
2.1 x 8-pin ATX 12V power connector
3.6 x SATA 6Gb/s connectors
4.1 x CPU fan header
5.3 x system fan headers
6.1 x front panel header
7.1 x front panel audio header
8.1 x S/PDIF Out header
9.1 x USB 3.0/2.0 header
10.3 x USB 2.0/1.1 headers
11.1 x serial port header
12.1 x parallel port header
13.1 x Clear CMOS jumper
14.1 x Trusted Platform Module (TPM) header

Connecteur du Panneau Arrière :
1.1 x PS/2 keyboard/mouse port
2.1 x D-Sub port
3.1 x DVI-D port
4.1 x HDMI port
5.4 x USB 3.0/2.0 ports
6.2 x USB 2.0/1.1 ports
7.1 x RJ-45 port
8.6 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out, Line In, Line Out, Mic In)

Contrôleur d'Entrée/Sortie :
1.iTE® I/O Controller Chip

Monitorage Matériel :
1.System voltage detection
2.CPU/System temperature detection
3.CPU/System fan speed detection
4.CPU/System overheating warning
5.CPU/System fan fail warning
6.CPU/System fan speed control
 * Whether the fan speed control function is supported will depend on the cooler you install.

BIOS :
1.2 x 64 Mbit flash
2.Use of licensed AMI UEFI BIOS
3.Support for DualBIOS™
4.PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Fonctionnalités Exclusives :
1.Support for APP Center
 * Available applications in APP Center may differ by motherboard model. Supported functions of each application may also differ depending on motherboard specifications.
 @BIOS
 EasyTune
 EZ Setup
 Fast Boot
 ON/OFF Charge
 Smart TimeLock
 Smart Recovery 2
 System Information Viewer
 USB Blocker
2.Support for Q-Flash
3.Support for Smart Switch
4.Support for Xpress Install

Logiciels Fournis :
1.Norton® Internet Security (OEM version)
2.Intel® Rapid Start Technology
3.Intel® Smart Connect Technology
4.Intel® Smart Response Technology
5.Intel® Small Business Advantage

Système d'Exploitation :
1.Support for Windows 8.1/8/7

Dimensions :
1.Micro ATX Form Factor; 24.4cm x 22.5cm

Remarque :
1.Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
2.Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
